Robertshaw Thermostat ( 5600 Series )

RM 0.00


Robertshaw 5600 Series Water Heater Thermostat

The 5600 series electric water thermostats are designed for replacement on domestic and commercial water heaters

The 5600 series features thermostat (automatic cycling) and high limit (manual reset) in one small housing. Compact size (3-3/4" overall length) assures firm clamp to tank. Controls have snap action operation, fast and easy wiring, and adjustable temperature ranges.

  • UL file # E47244. CSA file # LR57161

Specifications :

Thermostat control

30 amp @ 120-250 VAC
22 amp @ 277 VAC
12.5 amp @ 480 VAC
125 VA pilot duty @ 120-480 VAC

Hi-Limit Control (Manual reset portion)40 amp @ 277 VAC
25 amp @ 480 VAC
125 VA pilot duty @ 120-480 VAC
Wattage input3600 W @ 120 VAC
7200 W @ 240 VAC


Part numberReplacementTypical applicationSwitch typeTemperature rangeDifferential temperature
5600-3105600-210/EWT1L2SingleSPST / DPST
High Limit
120-160°C, ±5°C
Limit 190°C, ±5°C
7 - 17°C
5600-3115600-211/EWT2L2UpperSPDT / DPST
High Limit
120-160°C, ±5°C
Limit 190°C, ±5°C
17 - 27°C
5600-4115600-011/EWT1LowerSPST120-160°C, ±5°C7 - 17°C

Note :

All the above descriptions are subject to change without notice

Picture is for illustration only

Delivery : 3 to 5 days (in-stock unit) else 2 to 4 weeks (pre-order unit) subject to factory confirmation

Goods sold are non-returnable

Subject to minimum order quantities

Free Shipping Within Malaysia
